5-Axis
DMG DMU 85 monoBLOCK
- Year: 2017
- Travel Inch (X,Y,Z): 36.8 X 33.5 X 25.6
- Travel Metric (X,Y,Z): 935 X 850 X 650
- RPM: 15,000
- Spindle: SK 40
- ATC: 60 Tools
- Control: iTNC640 with HSCI
- Table Load: 1,000 kg / 2,205 lbs
- Equipped with: FCS, BLUM A3, OMP 60
3-Axis
Takumi H16
- Year: 2019
- Travel Inch (X,Y,Z): 62.9 X 51.1 X 27.5
- Travel Metric (X,Y,Z): 1600 X 1300 X 700
- RPM: 10,000
- Spindle: CAT 50 BIG PLUS
- ATC: 40 Tools
- Control: iTNC530
- Table Load: 6,000 kg / 13,200 lbs
- Equipped with: FCS, BLUM A3, RMP60
Okuma M560V
- Year: 2018
- Travel Inch (X,Y,Z): 41.34 X 22.05 X 18.11
- Travel Metric (X,Y,Z): 1050 X 560 X 460
- RPM: 15,000
- Spindle: CAT 40 BIG PLUS
- ATC: 32 Tools
- Control: OSP-P300
- Table Load: 898 kg / 1,980 lbs
- Equipped with: FCS, NC-4, RMP600
Awea AF-1600
- Year: 2017
- Travel Inch (X,Y,Z): 63.00 X 31.50 X 31.50
- Travel Metric (X,Y,Z): 1600 X 800 X 800
- RPM: 15,000
- Spindle: BT40
- ATC: 40 Tools
- Control: Fanuc Oi-MF
- Table Load: 1,500 kg / 3,307 lbs
- Equipped with: FCS, BLUM A4
Quaser MV184V/15C
- Year: 2014
- Travel Inch (X,Y,Z): 40.16 X 24.02 X 24.02
- Travel Metric (X,Y,Z): 1,020 X 610 X 610
- RPM: 15,000
- Spindle: CAT 40
- ATC: 30 Tools
- Control: iTNC530
- Table Load: 500 kg / 1,102 lbs
- Equipped with: FCS, BLUM TC50, 4th Axis
Fadal 4020
- Year: 2003
- Travel Inch (X,Y,Z): 40 X 20 X 20
- Travel Metric (X,Y,Z): 1016 X 508 X 508
- RPM: 10,000
- Spindle: CAT 40
- ATC: 21 Tools
- Control: Fanuc
- Table Load: 598 kg / 1,320 lbs
- Equipped with: FCS
Milltronics VM24
- Year: 1998
- Travel Inch (X,Y,Z): 40 X 24 X 24
- Travel Metric (X,Y,Z): 1016 X 610 X 610
- RPM: 6,000
- Spindle: CAT 40
- ATC: 20 Tools
- Control: Centurion 6
- Table Load: 680 kg / 1,500 lbs
- Equipped with: FCS
Boring Mills
Kuraki KBT-11DX.A
- Year: 1998
- Travel Inch: 66.93 X 49.21 X 45.28 X 25.59
- Travel Metric: 1700 X 1250 X 1150 X 650
- RPM: 5 - 2,500
- Spindle: CAT 50
- Tool Changer: 40 Tools
- Control: Fanuc 15M-B
- Table Load: 4,990 kg / 11,000 lbs
- Equipped with: FCS
Machining Systems HMC-100
- Year: 1998
- Travel Inch (X,Y,Z): 72 X 40 X 40
- Travel Metric (X,Y,Z): 1829 X 1016 X 1016
- B Axis: 360 Deg
- RPM: 15 - 2,400
- Spindle: CAT 50
- ATC: 30 Tools
- Index Degree: 1 Deg
- Control:
- Table Load: 4,535 kg / 10,000 lbs
- Equipped with: FCS
Quality Equipment
HandySCAN BLACK™|Elite
- Accuracy: 0.0009 in (0.025 mm)
- Volumetric accuracy: 0.0008 in + 0.0005 in/ft (0.020 mm + 0.040 mm/m)
- Measurement resolution: 0.0009 in (0.025 mm)
- Mesh resolution: 0.0039 in (0.100 mm)
- Measurement rate: 1,300,000 measurements/s
- Light source: 11 blue laser crosses (+ 1 extra line)
- Part size range: 0.15-13 ft (0.05-4m)
- Software: VXelements/Polyworks
